Plastic Valves

Features

Water-tight seal between the body and bonnet for maximum confidence, even in the most extreme conditions
Robust construction and electrical design for quiet performance you can count on
Filtered pilot flow to resist debris and clogging
Slow closing to prevent water hammer and subsequent system damage
Normally closed, forward flow design Accepts latching solenoid for use with Rain Bird battery-operated controllers
Multi-drive screws (Phillips, flathead, hexagonal) for easy maintenance
Manual internal bleed operates the valve without allowing water into the valve box. This allows the pressure regulator to be adjusted without turning the valve on at the controller
One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service Three-year trade warranty
Accommodates optional, field-installed PRS-D pressure regulating dial to ensure optimum sprinkler performance
Accepts latching solenoid for use with Rain Bird battery-operated controllers
Options
Accommodates optional, field installed PRS-D pressure regulating module to ensure optimum sprinkler performance. Regulates up to 100 psi (6.9 bar)
Accepts latching solenoid for use with Rain Bird battery-operated controllers up to 150 psi (10,35 bar)
Compatible with ESP-LXD and ESP-LXIVM decoders

Specifications

Pressure: 15 to 150 psi (1.04 to 10.4 bar)
Flow without PRS-D option: 2 to 150 gpm (0.45 to 34.05 m3/h; 7.8 to 568 l/m)
Flow with PRS-D option: 5 to 150 gpm (1.14 to 34.05 m3/h; 19.2 to 568 l/m)
Water temperature: Up to 110° F (43° C)
Ambient temperature: Up to 125° F (52° C)
24VAC 50/60Hz (cycles/sec) solenoid power requirement
Inrush current: 0.41A (9.9VA) at 50/60Hz
Holding current: 0.14A (3.43VA) at 50/60Hz
Solenoid coil resistance: 30-39 Ohms, nominal

Dimensions

Height  x Length  x Width
100-PGA: 7 1⁄4" (18.4 cm) x 5 1⁄2" (14.0 cm) x 3 1⁄4" (8.3 cm)
150-PGA: 8" (20.3 cm) x 6 3⁄4" (17.2 cm) x 3 1⁄2" (8.9 cm)
200-PGA: 10" (25.4 cm) x 7 3⁄4" (19.7 cm) x 5" (12.7 cm)

Model Listing

NPT Models

  • 100-PGA: 1” NPT
  • 150-PGA: 1.5” NPT
  • 200-PGA: 2” NPT

    • BSP w/ TBOS Solenoid Models

  • I-100-PGA-9V: 1” BSP
  • I-150-PGA-9V: 1.5” BSP
  • I-200-PGA-9V: 2” BSP

    • BSP Models

  • I-100-PGA: 1” BSP
  • I-150-PGA: 1.5” BSP
  • I-200-PGA: 2” BSP

    • Features

    Best-in-Class Valves
    With industry-leading reliability and performance, the Rain Bird PGA Series of commercial valves are now even better with preinstalled IVM-SOL
    Next Generation Two-Wire System
    The ESP-LXIVM Two-Wire Controller is the next leap forward—simplifying installation, improving reliability and enabling more troubleshooting features that save time
    Performance and Reliability
    With 50% fewer connections, an IVM Smart Valve is already 200% more reliable out of the box versus using a valve and decoder
    Features
    Globe and angle configuration for flexibility in design and installation
    PVC and glass reinforced nylon construction
    Filtered pilot flow to resist debris and clogging of solenoid ports
    Slow closing to prevent water hammer and subsequent system damage
    Manual internal bleed operates the valve without allowing water into the valve box
    One-piece solenoid design with captured plunger and spring for easy servicing prevents loss of parts during field service
    Non-rising flow control handle adjusts water flows as needed
    Normally closed, forward flow design
    Options (order separately)
    Accommodates optional, field installed PRS-D pressure regulating module

    Specifications

    Accommodates optional, field installed PRS-D pressure regulating module
    Flow: 2 –150 gpm (0.45 to 34.05 m3/h; 7.8 to 568 l/m)
    Flow with PRS-D: 5 –150 gpm (1.14 to 34.05 m3/h; 19.2 to 568 l/m)
    Water Temperature: up to 110° F (43° C)
    Ambient Temperature: up to 125° F (52° C)
    Electrical Specifications
    Power: 26.5 Vrms 50/60 Hz (cycles/sec)
    Inrush current: <40mA (Peak)
    Quiescent current: <0.4mA (ave.)
    Voltage range: 15.6 - 29.2 Vrms
    Compatible with LXIVM controllers
    Dimensions (H x W x L)
    IVM100PGA: 7.25” (18.4 cm), 5.5” (14.0 cm), 3.25” (8.3 cm)
    IVM150PGA: 8” (20.3 cm), 6.75” (17.2 cm), 3.5” (8.9 cm)
    IVM150PGA: 10” (25.4 cm), 7.75” (19.7 cm), 5” (12.7 cm)

    Model Listing

  • IVM100PGA: 1" Valve with IVM-SOL
  • IVM150PGA: 1.5" Valve with IVM-SOL
  • IVM200PGA: 2" Valve with IVM-SOL

    • Features

    Durable glass-filled nylon construction with fabric-reinforced rubber diaphragm for long life and reliable performance
    Globe configuration
    Normally closed, forward flow design
    Slow closing to prevent water hammer and subsequent system damage
    Low flow capability for a wide range of applications
    One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service
    Flow control handle adjusts water flows as needed
    Manual internal bleed manually operates the valve without allowing water into the valve box; allows pressure regulator to be adjusted without turning the valve on at the controller first
    Manual external bleed permits flushing debris from the system. Recommended for system start up and after repairs
    Stainless steel studs molded into the body. Bonnet can be attached and removed more easily and more often without damaging threads
    Nylon scrubber scrapes a stainless steel screen to clean and break down grit and plant material. Prevents debris build-up and clogging (PESB Series only)
    Five-year trade warranty

    Specifications

    Pressure: 20 to 200 psi (1.4 to 13.8 bar)
    Flow without PRS-D option: 0.25 to 300 GPM (0.06 to 68.1 m3/h; 0.02 to 18.90 l/s)
    Flow with PRS-D option: 5 to 300 GPM (1.14 to 68.1 m3/h; 0.32 to 18.90 l/s)
    Temperature: Up to 150° F (66° C)
    Power: 24VAC 50/60Hz (cycles/sec) solenoid power requirement
    Inrush current: 0.41A (9.9VA) at 50/60Hz
    Holding current: 0.14A (3.43VA) at 50/60Hz
    Options
    Accommodates optional, field-installed PRS-D pressure regulating module to ensure optimum sprinkler performance Regulates up to 100 psi (6.9 bar)
    Accepts latching solenoid for use with Rain Bird battery-operated controllers up to 150 psi (10.35 bar)
    Compatible with ESP-LXD decoders
    Optional purple flow control handle for non-potable water applications PEB-NP-HAN1 (1"); PEB-NP-HAN2 (1½" and 2")

    Dimensions

    100-PEB: 6½" x 4" x 4" – (16.5 cm) x (10.2 cm) x (10.2 cm) H x L x W
    150-PEB: 8" x 6" x 6" – (20.3 cm) x (15.2 cm) x (15.2 cm) H x L x W
    200-PEB: 8" x 6" x 6" – (20.3 cm) x (15.2 cm) x (15.2 cm) H x L x W
    300-PESB: 13 1/4" x 8" x 7" – (34.61 cm) x (20.32 cm) x (17.78 cm) H x L x W

    Model Listing

  • 100-PEB and 100-PESB: 1" NPT
  • 150-PEB and 150-PESB: 1 1⁄2" NPT
  • 200-PEB and 200-PESB: 2" NPT
  • 300-PESB: 3" NPT
  • Note: BSP threads available; specify when ordering

    • Features

    Plastic diaphragm and scrubber components molded of chlorine- and chemical-resistant plastic material
    Durable glass-filled nylon construction for long life and heavy-duty performance at 200 psi (13,80 bars) pressure
    Stainless steel studs molded into the body. Bonnet can be attached and removed easily without damaging threads
    One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service
    External bleed protects the solenoid ports from debris when system is flushed
    Internal bleed operates the valve without allowing water into the valve box; allows pressure regulator to be adjusted without turning on the valve at the controller first
    Slow closing to prevent water hammer and subsequent system damage
    Scrubber mechanism scrapes stainless steel screen clean to break down grit and plant material
    Purple flow control handle standard on PESB-R Series valves
    Five-year trade warranty
    Options
    Accommodates optional, field installed PRS-D pressure regulating module to ensure optimum sprinkler performance. Regulates up to 100 psi (6.9 bar)
    Accepts latching solenoid for use with Rain Bird battery-operated controllers up to 150 psi (10.35 bar)
    Compatible with ESP-LXD decoders

    Specifications

    Pressure: 20 to 200 psi (1.38 to 13.80 bar)
    Flow: 0.25 to 200 gpm (0.06 to 45.40 m3⁄h; 0.02 to 12.60 l/s)
    Flow with PRS-Dial: 5 to 200 gpm (1.14 to 45.40 m3⁄h; 0.32 to 12.60 l/s)
    Temperature: Up to 150° F (66° C)
    Power: 24VAC 50/60Hz (cycles/sec) solenoid power requirement
    Inrush current: 0.41A (9.9VA) at 50/60Hz
    Holding current: 0.14A (3.43VA) at 50/60Hz
    Solenoid coil resistance: 30-39 Ohms, nominal

    Dimensions

    100-PESB-R: 6 1⁄2" x 4" x 4" (16.5 cm) x (10.2 cm) x (10.2 cm) H x L x W
    150-PESB-R: 8" x 6" x 6" (20.3 cm) x (15.2 cm) x (15.2 cm) H x L x W
    200-PESB-R: 8" x 6" x 6" (20.3 cm) x (15.2 cm) x (15.2 cm) H x L x W

    Model Listing

  • 100-PESB-R: 1" NPT
  • 150-PESB-R: 1½" NPT
  • 200-PESB-R: 2" NPT

    • Features

    Best-in-Class Valves
    With industry-leading reliability and performance, the Rain Bird PEB/PESB Series of commercial valves are now even better with preinstalled IVM-SOL
    Next Generation Two-Wire System
    The ESP-LXIVM Two-Wire Controller is the next leap forward—simplifying installation, improving reliability and enabling more troubleshooting features that save time
    Performance and Reliability
    With 50% fewer connections, an IVM Smart Valve is already 200% more reliable out of the box versus using a valve and decoder
    Features
    Body constructed of durable glass-filled nylon for long life and heavy-duty performance at 200 psi (13.80 bar) pressure
    Stainless steel studs molded into the body. Bonnet can be attached and removed more easily without damaging threads
    One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service
    External bleed protects the solenoid ports from debris when system is flushed
    Internal bleed operates the valve without allowing water into the valve box; allows pressure regulator to be adjusted without turning on the valve at the controller first
    Low flow operating capability (0.25 gpm; 0.06 m3/h; 1.2 l/m) for a wide range of applications. For flows below 5 gpm (1.14 m3⁄h; 19.2 l/m) or any Xerigation® application, install Rain Bird Y filter upstream
    Slow closing to prevent water hammer and subsequent system damage
    PESBIVM only: Scrubber scrapes its stainless steel screen clean to break down grit and plant material. Prevents debris build-up and clogging
    Options (order separately)
    Accommodates optional, field installed PRS-D pressure regulating module to ensure optimum sprinkler performance
    Optional purple flow control handles for non-potable water applications: PEB-NP-HAN1(1”) & PEB-NP-HAN2 (11⁄2” and 2”)

    Specifications

    Pressure: 20 to 200 psi (1.38 to 13.80 bar)
    Flow: 0.25 to 200 gpm (0.06 to 45.40 m3⁄h; 1.2 to 757 l/m)
    Flow with PRS-D: 5 to 200 gpm (1.14 to 45.40 m3⁄h; 19.2 to 757 l/m)
    Temperature: up to 150° F (66° C)
    Electrical Specifications
    Power: 26.5 Vrms 50/60 Hz (cycles/sec)
    Inrush current: <40mA (Peak)
    Quiescent current: <0.4mA (ave.)
    Voltage Range: 15.6 - 29.2 Vrms
    Compatible with LXIVM controllers
    Dimensions (H x L x W)
    100 - 6.5” (16.5 cm), 4” (10.2 cm), 4” (10.2 cm)
    150 - 8” (20.3 cm), 6” (15.2 cm), 6” (15.2 cm)
    200 - 8” (20.3 cm), 6” (15.2 cm), 6” (15.2 cm)

    Model Listing

  • 100PEBIVM & 100PESBIVM: 1" Valve with IVM-SOL
  • 150PEBIVM & 150PESBIVM: 1.5" Valve with IVM-SOL
  • 200PEBIVM & 200PESBIVM: 2" Valve with IVM-SOL

    • Features

    Allows the filter to be safely placed downstream of the valve since these valves handle all sizes of particles
    Unique “double-knife” diaphragm coupled with ½" diameter seat for flawless operation at low flow rates
    Low Flow Valve is available in ¾" In-line model
    Double-filtered pilot flow design for maximum reliability
    External bleed to manually flush the system of dirt and debris during installation and system start-up
    Internal bleed for spray-free manual operation

    Specifications

    Operating Range
    Flow: 0.20 to 10.0 gpm (0.6 to 37.8 l/m)
    Pressure: 15 to 150 psi (1.0 to 10.3 bar)
    Electrical Specifications
    24 VAC 50/60 Hz (cycles/sec) solenoid
    Inrush current: 0.30 (7.2 VA) at 60 Hz
    Holding current: 0.19 A (4.56 VA)

    Model Listing

  • LFV-075: ¾" Low Flow DV Valve
  • LFV-100*: 1" Low Flow DV Valve
  • * Available with BSP threads

    • Features

    Combination of the reliable DVF Angle valve and atmospheric backflow preventer in one unit
    Incorporates all features of DV/DVF Series valves
    I.A.P.M.O. and A.S.S.E. listing approved
    City of Los Angeles listing approved
    Not recommended for use with two-wire control systems

    Specifications

    Pressure: 15 to 150 psi (1,0 to 10,4) bar
    075-ASVF Flow: 0.2 to 22 GPM (0,05 to 5,0 m³/h; 0,01 to 1,39 l/s). For flows below 3 GPM (0,68 m³h; 0,19 l/s) or any Landscape Drip products application, use a 200 mesh filter installed upstream
    100-ASVF Flow: 0.2 to 40 GPM (0,05 to 9,085 m³/h; 0,01 to 2,52 l/s). For flows below 3 GPM (0,68 m³h; 0,19 l/s) or any Landscape Drip products application, use a 200 mesh filter installed upstream
    Water temperature: Up to 110°F (43°C)
    Ambient air temperature: Up to 125°F (52°C)
    Solenoid coil resistance: 38 Ohms
    24 VAC 50/60Hz (cycles per second) solenoid power requirement: 0.450A inrush current; 0.250A holding current
    Installation Notes
    Anti-siphon valve must be installed upright
    Anti-siphon unit must be installed at least 6" (15,2 cm) above the highest point of water in the pipe and sprinklers it serves
    No valve can be located downstream of the anti-siphon valve
    Anti-siphon valves must not be subjected to operating pressure for more than twelve (12) hours in any twenty-four (24) hour period
    Uniform Plumbing Code Sec. 1003 (2) 602.2  Consult local codes
    Recommendations
    Rain Bird recommends flow rates that result in discharge velocities in the supply line not to exceed 7.5 ft/sec (2.3 m/s) in order to reduce the effects of water hammer
    Rain Bird residential valves cannot be used with PRS pressure regulating modules
    Not recommended for use with two-wire systems

    Dimensions

    Height: 6 ¼" (15.8 cm)
    Length: 6 1/10" (15.5 cm)
    Width: 3 1/5" (8.1 cm)

    Model Listing

  • 075-ASVF: ¾" (20/27)
  • 100-ASVF: 1" (26/34)
  • Note: Models available in NPT threads only

    • Features

    Double-filtered (diaphragm and solenoid) pilot-flow design for maximum reliability and grit resistance
    Buna-N, balanced pressure diaphragm with self-cleaning 90 mesh (200 micron) pilot water filter and captive spring
    Energy-efficient, low-power encapsulated solenoid with captured plunger and 90-mesh (200 micron) solenoid filter
    Unique, easy-to-turn pressure assisted flow control mechanism (DVF models only)
    External bleed to manually flush the system of dirt and debris during installation and system start-up
    Internal bleed for spray-free manual operation
    Accepts Rain Bird TBOS latching solenoid for use with most battery-operated controllers
    Operates in low-flow and Landscape Drip applications when a 200 mesh filter is installed upstream
    *Not recommended for use with two-wire control systems

    Specifications

    Pressure: 15 to 150 psi (1,0 to 10,4 bar)
    075-DV Non-Flow Control Model: 0.2 to 22 GPM (0,05 to 5,0 m³/h; 0,01 to 1,39 l/s). For flows below 3 GPM (0,68 m³/h; 0,19 l/s) or any Landscape Drip application, use a 200 mesh filter installed upstream
    100-DV Non-Flow Control Model: 0.2 to 40 gpm (0,05 to 9.085 m³/h; 0,01 to 2,52 l/s). For flows below 3 gpm (0,68 m³/h; 0,19 l/s) or any Landscape Drip application, use a 200 mesh filter installed upstream
    100-DVF Flow Control Model: 0.2 to 40 gpm (0,05 to 9.085 m³/h; 0,01 to 2,52 l/s); For flows below 3 gpm (0,68 m³/h; 0,19 l/s) or any Landscape Drip application, use a 200 mesh filter installed upstream
    Water temperature: Up to 110°F (43°C)
    Ambient air temperature: Up to 125°F (52°C)
    Solenoid coil resistance: 38 Ohms
    24 VAC 50/60Hz (cycles per second) solenoid power requirement: 0.450A inrush current, 0.25A holding current
    Dimensions: DV Valves
    Height: 4½" (11,4 cm)
    Height (Angle): 5½" (14 cm)
    Length: 4 3/8" (11.1 cm)
    Length (Angle): 3¾" (9.5 cm)
    Length (MB): 5¾" (14.6 cm)
    Width: 3 1/3" (8.4 cm)
    Dimensions: DVF Valves
    Height : 5 3/5" (14.2 cm)
    Length: 4 3/8" (11.1 cm)
    Length (MB): 5¾" (14.6 cm)
    Width: 3 1/3" (8.4 cm)
    Recommendations:
    Rain Bird recommends flow rates that result in discharge velocities in the supply line not to exceed 7.5 ft/sec (2.3 m/s) in order to reduce the effects of water hammer
    Rain Bird residential valves cannot be used with PRS pressure regulating modules
    Compatible with ESP-LXIVM 2-wire systems when used with the IVMSOL. Not recommended for use in other 2-wire systems

    Model Listing

  • 075-DV: 3/4" (20/27) NPT
  • 100-DV: 1" (26/34) NPT female x female*
  • 100-DV-SS: 1" (26/34) slip x slip
  • 100-DV-A: 1" (26/34) NPT female x female*
  • 100-DV-MB: 1" (26/34) male x barb
  • 100-DVF: 1" (26/34) NPT female x female*
  • 100-DVF-SS: 1" (26/34) slip x slip
  • *Available with BSP threads

    • Features

    Patented, eccentric, balanced pressure, Buna-N diaphragm with self-cleaning 90-mesh (200 microns) pilot water filter and captured stainless steel spring – Eccentric design provides smoother closing, less water hammer
    Only four durable, captured multi-drive bonnet screws that come out with half the number of turns for fast and easy servicing – at least twice as fast as the competition
    Glass-filled polypropylene body for strength (slip by slip model bodies are PVC)
    All popular model configurations available
    Compact design, 2.54" spin radius for tight installations
    Reverse flow, normally closed design
    External bleed to manually flush the system of dirt and debris during installation and system start-up
    Internal bleed for spray-free manual operation
    Operates in low-flow and Landscape Drip applications when a 200 mesh filter is installed upstream

    Specifications

    Pressure: 15 to 150 PSI (1,0 to 10,3 bar)
    Flow: 0.2 to 30 GPM (0,05 to 6,82 m3/h; 0,01 to 1,89 l/s); for flows below 3 GPM (0,68 m3/h; 0,19 l/s) or any Landscape Drip application, use a 200 mesh filter installed upstream
    Operating Temperatures: Water temperature up to 110° F (43° C); ambient temperature up to 125° F (52° C)
    Inrush current: 0.290A at 50/60 Hz
    Holding current: 0.091A at 50/60 Hz
    Solenoid Coil resistance: 70-85 Ohms (40° F - 110° F)
    24 VAC 50/60 Hz (cycles/sec.) solenoid

    Dimensions

    Height: 4.62" (11.7 cm)
    Height: (F): 5.62" (14.3 cm)
    Height: (MB): 4.50" (11.4 cm)
    Length: 4.4" (11.2 cm)
    Length: (MB): 5.68" (14.4 cm)
    Width: 3.1" (7.9 cm)

    How to Specify

    HV Series - How to Specify

    Model Listing

  • 100-HV-NPT: 1" NPT female x female*
  • 100-HV-SS: 1" slip x slip
  • 100-HV-MB: 1" male x barb
  • 100-HVF-SS: 1" slip x slip

    • Copyright © 2024 Rain Bird Corporation. All rights reserved.
