Rain Bird Block Rotors

Engineered to Water Efficiently

(DISCONTINUED)

Rain Bird block rotors are designed for the harsh conditions encountered in golf applications.  Engineered for precise application and distribution uniformity, Rain Bird block rotors help you get the most from your water source. With intelligent, easy-to-use features like a top-serviceable design and quick full- or part-circle adjustments, Rain Bird golf rotors help you and your crew save time every week.

Features

Unique Features

Block rotors feature low flow bearing guides and custom retract springs designed specifically for applications utilizing multiple rotors on an electric valve.  The water saving Seal-A-Matic check valve prevents low head drainage by holding back 10’ (3.1m) of elevation change, protecting both your turf and your pipe network.

Timeless Compatibility

Timeless Compatibility™

Designed for Timeless Compatibility™ with every EAGLE® rotor manufactured since 1992, these rotors give you the flexibility to update internals without having to dig up the case, saving you even more time.

Top Serviceability

With superior performance in a smaller footprint than competing rotors and an intelligent snap-ring design for quick access to serviceable components, Rain Bird rotors have long been the perfect choice for golf courses.

Specs

Radius

  • Rain Bird 551: 32' to 55' (9.8 m to 16.8 m)
  • Rain Bird 700: 57' to 77' (17.4 m to 23.5 m)
  • Rain Bird 751: 32' to 73' (9.8 m to 22.3 m)

Flow Rate

  • Rain Bird 551: 6.83 to 13.63 gpm (0.43 to 0.86 l/s); (1.55 to 3.10 m³/h)
  • Rain Bird 700: 16.3 to 43.8 gpm (1.03 to 2.76 l/s); (3.70 to 9.95 m³/h)
  • Rain Bird 751: 7.0 to 37.7 gpm (0.44 to 2.38 l/s); (1.59 to 8.56 m³/h)

Arc

  • Full-circle, 360°
  • Part-circle, 30-345°

Maximum Inlet Pressure

  • 100 psi (6.9 bars)

Dimensions

  • Body Height: 9.6" (24.5 cm)
  • Pop-Up Height to Mid-Nozzle: 2.6" (6.6 cm)
  • Top Diameter: 4.25" (10.8 cm)

Maximum Stream Height

  • Rain Bird 551: 51 Nozzle: 5' (1.5 m), 52, 53, 54 Nozzles: 13' (4.0 m)
  • Rain Bird 700/751: Standard Nozzle: 17' (5.2 m), Wind Tolerant: 10' (3.1 m)
  • Rain Bird 751: Low Angle: 12' (3.7 m)

Nozzle Trajectory

  • Rain Bird 551: 51 Nozzle: 12°, 52, 53, 54 Nozzles: 25°
  • Rain Bird 700/751: Standard Nozzle: 25°, Wind Tolerant: 10°
  • Rain Bird 751: Low Angle: 15°

Inlet Threads

  • 1" (2.5 cm) ACME

Holdback

  • 10' (3.1 m) of elevation

Rotation Time

  • 180° in ≤ 90 seconds, 75 seconds nominally

Top-Serviceable Internal Components

  • Yes
