1" Wide Flow Control Zone Kit for Light Commercial
Wide Flow Commercial Control Zone with easy to clean, Pressure-regulating (PR) Basket Filter
The Control Zone Kit for Light Commercial applcations is designed to last in the most punishing conditions while being easy to maintain.
- Wide Range: Includes the flexible and proven PEB valve with wide flow range.
- Easy Clean Filter: Basket filter with "no spill" feature ensures dirt does not fall back into the filter during cleanup operation. The threaded filter top with 0-ring makes it easy to remove and clean that stainless steel filter screen.
- Long-term reliability: Provides on/off control, filtration, and pressure regulation with only two parts; so there is less chance of leakage at the connections, both at installation and over the life of the system.
Features
Valve - 100PEB
Filter type - Basket Filter; 200 mesh (75 micron)
Flow Rate Capability
(0.9 gph dripline with 12" emitter spacing) - 20 to 1300 ft (6 to 396m) of dripline
Valve box - Mini-Standard Rectangular
Warranty - 3yr Warranty
Controller compatibility -
Compatible with traditionally-wired controllers
Compatible with TBOS / DC controller when used with DC Latching solenoid
Compatible with IVM controllers (ESP-LXIVM/LXIVMP) when used with IVM SOL
Compatible with 2-wire decoder systems like ESP-LXD controller
Specs
Operating flow range - 0.3 to 20.0 gpm; (1.13 to 75.7 l/m)
Min diagnostic flow - N/A
Inlet pressure - 15 to 150 psi; (1,0 to 10,3 bar)
Regulated pressure - 40 psi (2.8 bar)
Additional Specification Notes
*For flows below 5 gpm Rain Bird recommends the use of upstream filtration to prevent debris from collecting below the diaphragm
Dimensions
LxWxH - 12" Length
Inlet Size - 1" x 1" NPT
Model Comparison
XCZ100PRF
IXCZ100PRF
ICZ1009V
XCZPGA100PRF
XCZ100IVM
