LFX600 Low Flow Sprinkler

Flow rate: 0.61 to 2.12 gpm (140 to 469 l/h)

LFX Low Flow Sprinklers offer unparalleled operational flexibility with both interchangeable brake assemblies and nozzles.  Featuring unmatched water distribution at all trajectories, the LFX600 is perfect for a wide variety of applications.

Low Flow Irrigation Logo  Five Year Warranty Logo

Features

  • Simple three part sprinkler design includes body, nozzle, and brake assembly with attached deflector
  • Each nozzle and brake assembly was designed to easily be changed with other sizes or outlet trajectories to maximize operational flexibility
  • Easy in-field maintenance with simple snap-in-place nozzle and brake assembly including visual indicators to ensure correct positioning
  • Engineered to provide superior distribution uniformity for low volume applications in either an under-tree or over-head configuration
  • Constructed of engineered thermoplastic materials for durability and weather resistance
  • Color-coded nozzles and deflectors for easy identification
  • Two flow control nozzle options for consistent flow of water across the pressure range or terrain changes

Applications

  • For agriculture, greenhouse, and nursery applications which require a small footprint or low-volume spinkler
  • Optimized for a wide variety of applications including orchard and field irrigation, environmental control, crop cooling, and dust control

Accessories

  • Stake options include: steel, fiberglass, or preassembled PVC assemblies
  • 10mm feedtube configurations include: coil for custom installation, precut pieces in 36" (76.2cm) or 48" (106.7cm) length with barb preintstalled (with or without stake adapter installed)
  • Variety of adapters for increased application flexibility

Specs

Operating Range

  • Pressure: 25 to 50 psi (1.72 to 3.45 bar)
  • Flow rate: 0.61 to 2.12 gpm (140 to 469 l/h)
  • Radius of throw: 22 to 31 feet (6.7 to 9.4 meters)

Sprinkler Body Options:

  • 1/2“ (13mm) NPT male pipe thread
  • Female ACME thread

Deflector Trajectory Outlets:

  • 9° Blue
  • 12° Pink
  • 15° Purple
  • 15° Gold

Nozzle Sizes:

  • 65 Gray (0.065", 1.65mm)
  • 70 White (0.070", 1.78mm)
  • 78 Dark Blue (0.078", 1.98mm)
  • 86 Orange (0.086", 2.18mm)
  • 94 Purple (0.094", 2.39mm)
  • 10 Yellow (0.102", 2.59mm)
  • F4 0.75 gpm (170.3 l/h) Flow Control
  • F5 1.0 gpm (227.1 l/h) Flow Control

Uniformity Select:

Not sure which deflector and nozzle are right for your project?

Try our Uniformity Select tool here.

Packaging Data:

  • Sprinkler can be ordered assembled from the factory or a la carte for ultimate field flexibility
  • Assembled sprinklers can be ordered in increments of 1; case quantity of 400
  • Sprinkler parts vary in order increment and case quantity; Nozzles: Order increment of 200; case quantity of 1,600.  Brake Assemblies: Order increment of 200; case quantity of 4,000. Bodies: Order increment of 1; case quantity of 400
  • Accessories and mounting options vary in order increment; call for details 1-800-HELLO-AG
